width of material min. 200 mm to max. 450 mmWEB WIDTH, FULL UV 9 COLOUR,has hot air units on 2 print stations,(as well as UV)turn bar x 1 can be moved to any unit as required,unit 9 used for varnish,Auto Register,4 x rotary die stations,has total job count (however no total counter),has inspection camera,waste rewind.NO DELAM/RELAM,CORONA TREATER,SHEETING STATION.No chiller unit but the piping is all there.Used to run cold water through the piping but had no chiller with the machine.
The maximum substrate thickness for a Comco Commander 450 is often around 400 gsm (grams per square meter), with a typical operational range of 230 gsm to 400 gsm.However, specific substrate thickness capabilities can vary depending on: The exact model variation (e.g., a "Comco C1-22" is mentioned in one source with the 230 gsm to 400 gsm range).The specific material being run (e.g., paper, film, carton, or label stock).The Comco Commander series is generally designed as a wide-web flexographic press for printing on a variety of flexible packaging and label materials.
With 2 x manuals, including wiring diagrams
Estimated Tooling: 88T,93Tx 2 plus sheeter,96T x 2 plus sheeter,98T,99T,100T,106T,116T plus sheeter,118T,120T,128T,144T plus sheeter 4 slots.ALL CYLINDERS REPEATS HAVE EQUIVALENT MAGNETIC BASES.Anilox rollers:3 x 800 lpi,4 x 700 lpi,3 x 550 lpi,3 x 500 lpi,3 x 400 lpi,1x 200 lpi Working condition. Dimensions: size approx. is 15 metres L x 3.5W x 2H . Video Link available on request
The maximum substrate thickness for a Comco Commander 450 is often around 400 gsm (grams per square meter), with a typical operational range of 230 gsm to 400 gsm.However, specific substrate thickness capabilities can vary depending on: The exact model variation (e.g., a "Comco C1-22" is mentioned in one source with the 230 gsm to 400 gsm range).The specific material being run (e.g., paper, film, carton, or label stock).The Comco Commander series is generally designed as a wide-web flexographic press for printing on a variety of flexible packaging and label materials.
With 2 x manuals, including wiring diagrams
Estimated Tooling: 88T,93Tx 2 plus sheeter,96T x 2 plus sheeter,98T,99T,100T,106T,116T plus sheeter,118T,120T,128T,144T plus sheeter 4 slots.ALL CYLINDERS REPEATS HAVE EQUIVALENT MAGNETIC BASES.Anilox rollers:3 x 800 lpi,4 x 700 lpi,3 x 550 lpi,3 x 500 lpi,3 x 400 lpi,1x 200 lpi Working condition. Dimensions: size approx. is 15 metres L x 3.5W x 2H . Video Link available on request
Comco Commander 450
P.O.A.
E&L 100% inspection system,URC 2.0 Advanced Operator Control System,Maximum unwind diameter 711 mm, Maximum rewind diameter single spindle 457 mm, Maximum rewind diameter dual spindle 400 mm ,maximum machine speed 1000 fpm / 300 m/min,Air supply 60 - 100 psi, Voltage 380-415 VAC / 3ph / 50 Hz, Twin web guides,Semi Auto Turret - this can be removed and just run a 75MM mandrel.Lower rewind,Razor and Sheer slitting,Label counter for clear on clear,End of roll pen parking system,76mm, 38mm and 25mm mandrels.Very good condition.Video Link available on request
Rotoflex VSI 330
P.O.A.
Max web width : 330mm Max. mother reel diameter : 750mm ,Max. trim reel diameter : 600mm Max. rewinder reel diameter (with 1 core) : 600mm,Single flexo unit,varnish, and laminate,2x Lam unwinds,1x matrix rewind,2x finished roll rewinds,1x die station(semi rotary/ rotary),1 GEW UV UNIT.Razor slitting section , second pass scanner, Has a print cylinder for spot printing,Tooling: Mag cylinder is 160z, has 1or2 flood coat cylinders with a sleeve,2 aniloxes,No spare UV lamps & No foiling. NO video available.Working condition.
Smag ECUT 330
P.O.A.
